Комутатор Cisco Catalyst 9200L 48-port PoE+ 4x10G uplink Switch

★★★★★ (0 ревюта)

CISCO

_модел C9200L-48P-4X-E

_цена 6630.93 лв.

_{код на продукта} 9151

_{наличност} при доставчик

Добави в количката

Описание на продукта

Cisco Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Essentials Виж характеристиките

Характеристики

Суич, тип

Fixed Port
Общ брой портове

52
Основни портове, тип

48x10/100/1000Base-T
Power Over Ethernet (PoE)

IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE; Available PoE Power: 740W* (Default primary power supply - PWR-C5-1KWAC), 1440W* (Optional secondary power supply - PWR-C5-1KWAC), *Limited by port number and port rating
Uplink портове

4x10GBase-T
Свободни (10GB) слотове

No
Управление

SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
Stackable

Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)
Fans

Fixed redundant
Захранване

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-1KWAC
Routing

Layer 3 Advanced
Памет (Flash, RAM)

Flash memory: 4 GB; RAM: 2 GB DRAM
Капацитет за маршрутизиране/превключване, Gbps

176 Gbps
Пропускателна способност, Mpps

261.9 Mpps
MAC адреси

16000 MAC address
VLAN (брой, стандарти)

VLAN IDs: 1024; IEEE 802.1Q VLAN
QoS

Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
L3 мрежови стандарти

IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]
IPv6 functionality

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Сигурност

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Размери (Ш, Д, В), mm

445 x 288 x 44
Опция за монтаж

Rackmount
Други

Задължителен е минимум 3-годишен лиценз DNA Essentials.
