Комутатор Cisco Catalyst 9200 24-port PoE+ Switch

★★★★★ (0 ревюта)

CISCO

_модел C9200-24P-A

_цена 6399.27 лв.

_{код на продукта} 9130

_{наличност} при доставчик

Добави в количката

Описание на продукта

Cisco Catalyst 9200 24-port PoE+ Switch, Network Advantage Виж характеристиките

Характеристики

Суич, тип

Fixed Port
Общ брой портове

24
Основни портове, тип

24x10/100/1000Base-T
Power Over Ethernet (PoE)

IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE; Available PoE Power: 370W* (Default primary power supply - PWR-C5-600WAC), 740W* (Optional secondary power supply - PWR-C5-600WAC), *Limited by port number and port rating
Uplink портове
Свободни (10GB) слотове

Modular uplink options (C9200-NM-4G, C9200-NM-4X)
Управление

SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP
Stackable

Cisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)
Fans

Field-Replaceable Units (FRU) redundant
Захранване

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-600WAC
Routing

Layer 3 Advanced
Памет (Flash, RAM)

Flash memory: 4 GB; RAM: 4 GB DRAM
Капацитет за маршрутизиране/превключване, Gbps

128 Gbps
Пропускателна способност, Mpps

190.4 Mpps
MAC адреси

32000 MAC address
VLAN (брой, стандарти)

VLAN IDs: 4096; IEEE 802.1Q VLAN
QoS

Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port
L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
L3 мрежови стандарти

Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4
IPv6 functionality

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Сигурност

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Размери (Ш, Д, В), mm

445 x 350 x 44
Опция за монтаж

Rackmount
Други

Задължителен е минимум 3-годишен лиценз DNA Advantage.
